MB705M2P-B_M.2 NVMe SSD PCIe 4.0 to 2.5" U.2 SSD Converter/Mounting Adapter

Product introduction

ICY DOCK's EZConvert MB705M2P-B converts an M.2 NVMe PCIe SSD into the exact dimensions and port locations as a standard 2.5-inch U.2 (SFF-8639) NVMe SSD without using any tools or screws for drive installation. The MB705M2P-B can be installed anywhere that accepts a bare 2.5-inch U.2 NVMe drive, such as a U.2 backplane, 2.5" mounting bracket, or ICY DOCK U.2 NVMe removable enclosures/mobile racks. The sturdy aluminum heat sink housing protects the delicate M.2 circuit board from bumps and drops, and work perfectly with the included thermal pad for optimal heat dissipation to keep your drive running cool, even under heavy load.
Removable Design

Because M.2 SSDs are not designed to be frequently swap, their connectors are very delicate, typically rated for only 250 insertion/removal cycles. The EZConvert MB705M2P-B has a durable U.2 connector rated for 10,000 insertion/removal cycles, allows you to add, remove, and replace drives without putting any wear on the internal connector.
Perfect Compatibility

EZConvert MB705M2P-B accepts any 30mm-80mm M.2 PCIe NVMe SSD (2230 / 2242 / 2260 / 2280) and gives it the exact same dimensions, port locations, and screw-hole locations as a standard 9.5mm U.2 NVMe SSD.
Tool-less installation

The 1-piece heat sink lid snaps on and off without screws or tools, revealing the drive bay for easy installation, removal, and replacement in only seconds.
The adjustable M.2 locker slides to accommodate all standard M.2 PCIe NVMe SSD drive lengths, including 2230 (30mm), 2242 (42mm), 2260 (60mm), and 2280 (80mm). The locker clips into the SSD screw hole to secure the drive without screws, saving you the hassle of dealing with tiny easy-to-lose screws while protecting your drive from vibration and movement damage.
(1).Adjust the M.2 locker to your desired M.2 NVMe SSD length.
(2).Insert the M.2 NVMe SSD into the M.2 connector.
(3).Press down the M.2 NVMe SSD.
(4).A “click” sound will be heard once the M.2 NVMe SSD is secured in place.
Because the MB705M2P-B uses the standardized 2.5-inch U.2 form-factor, it can be installed into any U.2 backplane, 2.5-inch mounting bracket, or ICY DOCK U.2 NVMe removable enclosures/mobile racks such as MB699VP-B for multi-drives or MB601VK-B / MB601VK-1B for a single drive.
Packed with Features

The dual-function full-metal lid protects delicate M.2 SSDs from bumps and drops. The aluminum lid also acts as a heat sink to keep NVMe drives at safe temperatures, even under heavy load.
The included thermal paste sticker can be attached on to the underside of the full-metal lid for increased heat dissipation.
For additional cooling performance, the bottom air vent can be cut out to make room for an M.2 heat sink, or for additional air flow.
The MB705M2P-B supports the full NVMe bandwidth specification of up to 64Gbps, letting you take full advantage of the fastest M.2 NVMe SSDs available.
Pair it with the USB 3.2 to U.2 NVMe SSD Reader (EZ-Adapter MB931U-1VB)

The EZ-Adapter MB931U-1VB is compatible with EZConvert MB705M2P-B and works with any USB ports, giving you the utmost flexibility of accessing M.2 NVMe On-the-Go.

Customizable ICY DOCK Drive Enclosures: Tailored to Meet TAA & UL Certification Standards and More!

At ICY DOCK, we understand the paramount importance of adhering to various industry and safety standards. While our standard products are already crafted with the highest quality in mind, we also provide our customers with the option to customize ICY DOCK drive enclosures and mobile racks to meet their specific certification requirements. This includes standards such as TAA and UL to wide temperature tests.

Our dedicated team is fully prepared to adjust product materials and designs to ensure complete compliance. Furthermore, we offer comprehensive guidance to our clients throughout the certification process. Our goal is to not only meet precise specifications but also ensure that our products successfully pass stringent tests. Below, you'll find a detailed table listing all the optional certifications that can be tested with our customizable solutions.

Optional Certifications Available for EZConvert MB705M2P-B
TAA	Trade Agreements Act Compliance
UL	Safety Standard Certification
UL94	Flammability of Plastic Materials
FCC	Federal Communications Commission Compliance
Wide Temperature	MIL-STD-810H - Method 501.7 & 502.7

Customizing ICY DOCK products for specific certifications involves fees for the creation of the certificates, including necessary testing. Please note that some certificates may require recurring fees to remain valid. For more details and inquiries,please contact us at tech@icydock.com

Main Feature

•	Convert your M.2 NVMe SSD into the 2.5” U.2 NVMe form factor with 9.5mm height)

•	Exact same dimensions, port locations, and screw-hole locations as a standard U.2 drive

•	Accepts any M.2 PCIe NVMe SSD from 30mm to 80mm in length (2230 / 2242 / 2260 / 2280)

•	10,000 insertion/removal cycle rated U.2 connector

•	Supports full Nvme bandwidth specification of 64Gbps

•	100% tool-less and screw-less M.2 drive installation

•	Dual-function aluminum heat sink and lid for optimal protection and cooling performance

•	Lower housing ventilation hole can pop out for additional air flow and improved cooling

•	Strong 1-piece ABS plastic lower body

•	Supports U.2 (SFF-8639) cables

•	Fits into any U.2 backplanes, 2.5-inch mounting brackets, or ICY DOCK U.2 NVMe SSD enclosures

•	Industry leading 3 year warranty with exceptional customer support

•	Complimentary technical support from trained US-based ICY DOCK support technicians

Specification

Model Number：	MB705M2P-B
Color：	Black
Support Drive Size：	1 x M / B + M key M.2 PCIe NVMe SSD 2230/2242/2260/2280
Compatible Drive Type：	M.2 PCIe 3.0/4.0 NVMe SSD
Number of M.2：	1
Host Interface：	1 x U.2 SFF-8639, pin-out defined by SFF-9402 Rev 1.1 (Tri-mode HBA/RAID card compatible)
Transfer Rate：	Up to 64Gbps
Support HDD Capacity：	No limitation
Structure / Material：	Aluminum & ABS plastic
Support Hot-Swap：	Yes
Product Dimension (W x H x D)：	70.0 x 9.5 x 101.0mm
Product Net Weight：	67g
Package Gross Weight：	99.5g
Package Contents：	Device, mounting screws, user manual, thermal pads
U.2 Connector Insertion Rate：	10,000
Humidity：	5%~65% RH
Operating Temperature：	0°C to 60°C (32°F to 140°F)
Storage Temperature：	-35°C to 70°C (-31°F to 158°F)
Compliance：	CE, RoHS, REACH
Warranty：	3 years

Related Products Series:

Quick Link:

FAQ

Q: Can you recommend an add-on card that works with MB705M2P-B?

A: The following add-on cards are compatible with MB705M2P-B. We highly recommend using the official cable for the best compatibility.

Supported Add-on Cards and Cables for MB705M2P-B

Note:We highly recommend purchasing the cable from a local reseller that you trust. However, if you have a hard time finding the cables, PC-Pitstop is our long term partner, and they are able to ship worldwide.

We are currently certifying our NVMe enclosure with the major add-on card manufacturers. We will be adding compatible add-on cards to the list.

You can click here to report a compatible add-on card/cable. If you want to check the compatibility of add-on card(s) that are not on the list, please click here.

Q: I'm using Intel/Broadcom Tri-Mode HBA and RAID cards with the MB705M2P-B, but the drives do not show up in my system?

A: The issue is caused by RAID card manufacturers using a different pinout for Tri-Mode cards than is typically used for U.2 connections. When using these cards with U.2 NVMe drives and cables, a U.2 enabler cable must be used for compatibility, which reverts the pinout back to standard U.2 specifications. For more information, please click here.

Q: The system does not detect the M.2 SSD I installed in the ICY DOCK enclosure. What should I do?

A: Since the M.2 SSD is not designed for hot-swapping, we highly recommend powering off the device/system before inserting or removing an M.2 SSD. If the system is still unable to detect the drive, follow the steps below to scan for new hardware manually:

Windows 11 / Windows 10 / Windows 8 – In the search box on the taskbar, type device manager, and click it from the menu. Once the device manager window pops up, right-click on the disk drive icon, and click scan for hardware changes.

Windows 7 – Right-click on the computer icon on the desktop, select properties, click device manager, right-click on the disk drive icon and then click scan for hardware changes.

Image result for disk drive scan for hardware changes

Q:Is the ICY DOCK NVMe enclosure supporting the PCIe 4.0 standard?

A: Yes, all ICY DOCK NVMe enclosures support the PCIe 4.0x4 standard, with up to 64Gbps transfer rates.

Reviews

By ServetheHome

"Construction of the Icy Dock MB705M2P-B is top-notch, rugged and a lid made of aluminum that acts as a heat sink for cooling."

Jul 5, 2019

By OCinside.de

"With this good overall result, the U.2 products Icy Dock EZConvert MB705M2P-B, Icy Dock ToughArmor MB601VK-B and the ASRock U.2 Kit receive a clear purchase recommendation from us and thus our OCinside.de Purchase Tip Award."

Nov 20, 2019
