•Supports 1 x 7.5mm height E3.S NVMe SSD
•Compatible with PCIe x4/ x8 /x16 Slot
•Supports PCIe Gen 5.0 x 4 speed up to 128Gbps
•Supports drive hot-plug without requiring the system to be powered down
•Active Power Technology (APT) – drive activity LED only powers up if there is a drive installed in the bay
•Optional 4-pin drive activity signal output - allows for easy transfer of the drive activity signal to the front of the computer case

•Supports RAID 0 / 1 / JBOD / BIG
•Uses 1x PCIe 3.0/4.0 x8 or x16 slot (PCIe Bifurcation x4, x4, x4, x4 for PCIe 16x and x4, x4 for PCIe 8x is required to access both drives)
•Adapts two 9.5mm height E1.S SSDs within a single PCIe slot space
•Single slot, full-height 3/4 length card specifications
•Includes a 50mm frameless fan for effective heat dissipation
•Sealed space design for maximized cooling efficiency
•Removable SSD caddy design for quick drive maintenance and replacements

•Accommodates 8 x M.2 NVMe SSD with drive lengths from 30mm to 80mm (2230 / 2242/ 2260 / 2280) in a single PCIe x16 expansion slot (Full-height, full-length)
• Featuring a Built-in PCIe Bifurcation Function, empowers users to access eight individual M.2 NVMe SSDs in systems that do not natively support PCIe Bifurcation
•Delivers unmatched transfer speeds of up to 128Gbps for each M.2 NVMe PCIe SSD.
•Effortless maintenance with removable drive trays featuring a tool-less design.
•Superior heat dissipation via integrated M.2 drive heat sinks and thermal pads.
•50mm blower fan ensuring optimal cooling for each M.2 NVMe SSD.

•Supports 1 x U.2/U.3 NVMe SSD with a height of up to 9.5mm
•Compatible with PCIe 4.0 x4/ x8 /x16 Slot
•Supports PCIe Gen 4.0 x 4 speed up to 64Gbps
•Supports drive hot-plug without requiring the system to be powered down
•Active Power Technology (APT) – drive activity LED only powers up if there is a drive installed in the bay
•Optional 2-pin drive activity signal output - allows for easy transfer of the drive activity signal to the front of the computer case

nvme_enclosures,metal_tray_enclosures

•Fits 2 x E1.S NVMe SSD, compatible with 9.5mm thickness.
•Uses 1x PCIe 3.0/4.0 x8 or x16 slot (PCIe Bifurcation x4, x4, x4, x4 for PCIe 16x and x4, x4 for PCIe 8x is required to access both drives)
•Supports hot-swap/hot-plug E1.S NVMe SSD.
•Removable drive tray with tool-less drive installation for easy drive maintenance.
•The eagle-hook lock system keeps the drive secured in the enclosure.
•Equipped with a 50mm blower fan for maximum thermal performance.

•Fits 2 x M.2 NVMe SSD with drive lengths from 30mm to 80mm (2230 / 2242/ 2260 / 2280 / 2580) in a single PCIe x8 expansion slot (Full-height, half-length)
•1 x PCIe 3.0 or 4.0 x8 / x16 expansion slot (motherboard required PCIe x8 slots bifurcated into x4/x4 or PCIe x16 slots bifurcated into x4/x4/x4/x4)
•Supports PCIe 5.0 transfer speeds up to 128Gbps per M.2 NVMe PCIe 5.0 x 2 SSD
•Removable drive tray with tool-less drive installation design for easy drive maintenance
•Integrated individual M.2 drive heat sinks and thermal pads for max heat dissipation
•Equipped with a 50mm blower fan offers maximum cooling to M.2 NVMe SSD
•Individual drive activity LED indicator (Solid green for power and flashing green for drive activity)

•Fits 2x M.2 PCIe NVMe SSD from 30-110mm (2230, 2243, 2260, 2280, 22110)
•Uses 1x PCIe 3.0/4.0 x8 or x16 slot (PCIe Bifurcation x4, x4, x4, x4 for PCIe 16x and x4, x4 for PCIe 8x is required to access both drives)
•Installs to a single-width full-height PCIe express slot
•Removable drive tray with tool-less drive installation for easy drive maintenance
•Eagle-hook lock system keeps the drive secured in the enclosure
•EMI- Grounding – protects the hard drive from electrical damage

metal_tray_enclosures,nvme_enclosures,high_density_enclosures

•Fits 4 x M.2 NVMe SSD with drive lengths from 30mm to 80mm (2230 / 2242/ 2260 / 2280) in a single PCIe x16 expansion slot (Full-height, half-length)
•Uses 1x PCIe 3.0/4.0x16 slot (PCIe Bifurcation x4, x4, x4, x4 for PCIe 16x is required to access both drives)
•Supports transfer speeds up to 64Gbps per M.2 NVMe PCIe SSD
•Removable drive tray with tool-less drive installation design for easy drive maintenance
•Integrated individual M.2 drive heat sinks and thermal pads for max heat dissipation
•Equipped with a 50mm blower fan offers maximum cooling to M.2 NVMe SSD
•Individual drive activity LED indicator (Solid green for power and flashing green for drive activity)

•Fits 1 x M.2 PCIe NVMe SSD with all drive length including 2230 (30mm), 2242 (42mm), 2260 (60mm), 2280 (80mm), and 22110 (110mm)
•Use 1 x PCIe 3.0/4.0 x4 interface, also supports installation into PCIe 4.0 x8, and x16 slots
•Install into a single-width full-height expansion slot
Optional screw holes available for low profile PCIe bracket (not included)
•Low profile design allows for multiple bays to be installed side-by-side in a modular design
•Integrated heat sink and ample ventilation for excellent passive cooling
•Tool-less drive installation design for easy drive maintenance and system upgrading

hdd_ssd_adapters

•Fits 1 x M.2 PCIe NVMe SSD with all drive length including 2230 (30mm), 2242 (42mm), 2260 (60mm), 2280 (80mm), and 22110 (110mm)
•Use 1 x PCIe 3.0/4.0 x4 interface, also supports installation into PCIe 4.0 x8, and x16 slots
•Install into a single-width full-height expansion slot
Optional screw holes available for low profile PCIe bracket (not included)
•Low profile design allows for multiple bays to be installed side-by-side in a modular design
•Integrated heat sink and ample ventilation for excellent passive cooling
•Tool-less drive installation design for easy drive maintenance and system upgrading

hdd_ssd_adapters

•Fits 1 x M.2 PCIe NVMe SSD with all drive length including 2230 (30mm), 2242 (42mm), 2260 (60mm), 2280 (80mm), and 22110 (110mm)
•Use 1 x PCIe 3.0/4.0 x4 interface, also supports installation into PCIe 4.0 x8 and x16 slots
•Install into a single-width full-height expansion slot
Optional screw holes available for low profile PCIe bracket (not included)
•Low profile design allows for multiple bays to be installed side-by-side in a modular design
•Tool-less drive installation design for easy drive maintenance and system upgrading
•Active Power Technology (APT) saves power by shutting the device down when no drive is installed

hdd_ssd_adapters/span>

•Fits 1x EDSFF E1.S SSD with a maximum drive thickness of 5.9mm
•Use 1x PCIe 4.0 x4 interface, also supports installation into PCIe 1.0/2.0/3.0/4.0 x4, x8, and x16 slots
•Support PCIe 4.0 x4 with transfer rates up to 64Gbps
•Includes half-height and full-height PCIe brackets
•Removable drive tray with tool-less drive installation design for easy drive maintenance
•Low profile design allows for multiple bays to be installed side-by-side in a modular design

•Fits 1x M.2 PCIe NVMe SSD with all drive length including 2230 (30mm), 2242 (42mm), 2260 (60mm), 2280 (80mm), and 22110 (110mm)
•Use 1x PCIe 3.0/4.0 x4 interface, also supports installation into PCIe 3.0/4.0 x8 and x16 slots
•Install into a single-width full-height/half-height PCIe expansion slot
•Removable drive tray with tool-less drive installation design for easy drive maintenance
•Low profile design allows for multiple bays to be installed side-by-side in a modular design
•Eagle-hook lock system keeps the drive secure in the enclosure

metal_tray_enclosures,nvme_enclosures,tool-less_tray_enclosures

•Compatible with Mac Pro 2008-2012 models with no driver required
•Fits 1x SATA hard drive or SSD from 7mm to 9.5mm in height
•Uses PCIe 2.0 x1 interface, also supports installation into PCIe 2.0 and PCIe 3.0 x1, x4, x8, and x16 slots
•Installs into single-width PCIe expansion slot
•PCIe interface provides both power and data transfer which ultimately reduce cable clutter
•Narrow design allows for multiple bays to be installed side-by-side in a modular design

metal_tray_enclosures,nvme_enclosures other_compatible_enclosures,sas_sata_enclosures
