•Supports 8 x 15mm / 9.5mm E1.S SSDs in a single 5.25" bay.
•PCIe Gen 5.0 x4 interface — up to 128Gbps per drive.
•Complies with UBM (SFF-TA-1005) backplane management standard.
•4 x MCIO 8i connectors support PCIe bifurcation (x4/x2/x1).
•Compatible with Broadcom, HighPoint, Areca, and other HBA/RAID cards.
•Supports Hot-Plug drive swapping.

•Converts 5.9mm or 8.01mm E1.S SSDs to 9.5mm E1.S mechanical form factor
•Converts 5.9mm or 8.01mm E1.S SSDs to 9.5mm E1.S mechanical form factor
•Fully compatible with standard 9.5mm E1.S trays, tool-less carriers, and hot-swap drive bays
•Full-metal construction enhances protection and passive cooling
•Includes both thin and thick thermal pads for optimal heat transfer
•Tool-less SSD installation

•Converts standard M.2 NVMe SSDs (2230/2242/2260/2280) to 9.5mm E1.S SSD form factor
•Fully matches E1.S mechanical and electrical specifications (SFF-TA-1006 + SFF-TA-1002)
•Compatible with PCIe Gen 3/4/5 NVMe SSDs for up to 128Gbps data rate
•Ideal for E1.S drive bays in enterprise servers, AI edge systems, and modular compute nodes
•Internal bridge connector minimizes M.2 connector wear from frequent insertions
•Full-metal housing ensures structural integrity, EMI shielding, and thermal dissipation
•Ideal for system builders, server OEMs, and platform engineers validating E1.S systems

•IPX5 water-resistant cover
•Fits 4x PCIe NVMe U.2/U.3 SSD, up to 15mm drive height
•Installs into any standard external 5.25" optical drive bay
•Uses 2x MCIO (SFF-TA-1016 8i) to connect
•Supports PCIe 5.0 specification with transfer rates up to 128Gb/s per drive bay
•Removable tray system for easy maintenance

•Supports 4 x 7.5mm E3.S NVMe SSDs
•Fits into a single external 5.25" optical drive bays
•Connects via 2 x MCIO 8i (SFF-TA-1016 8i) interfaces
•Supports NVMe hot-plug function (requires hot-plug support from both host and SSD)
•Complies with PCIe 5.0 specifications, offering transfer rates up to 128Gbps per drive bay
•Durable, full-metal enclosure meets flammability standards
•Equipped with dual high-performance 40 x 40 x 20mm cooling fans
•Removable drive tray design for easy drive maintenance
•Active Power Technology - Saves power by shutting off the enclosure when no drive is installed
•EMI Grounding - Protects SSDs from electrical damage
•Eagle-hook tray latch - Securely holds the drive tray inside the enclosure

•Supports 12 x 7.5mm E3.S NVMe SSDs
•Fits into 2 x standard external 5.25" optical drive bays
•Connects via 6 x MCIO 8i (SFF-TA-1016 8i) interfaces
•Supports NVMe hot-plug function (requires hot-plug support from both host and SSD)
•Complies with PCIe 5.0 specifications, offering transfer rates up to 128Gbps per drive bay

•Durable construction using heavy-duty metal, ideal for demanding environments in medical, industrial, and military applications
•Meets stringent flammability standards, ensuring safety across various sectors
•Accommodates two U.2/U.3 PCIe 5.0 SSDs, up to 15mm in height, and one slim optical disk drive (12.7mm)
•Supports fast PCIe 5.0, enabling speeds up to 128Gbps for quick data transfer
•Features a removable caddy system for U.2/U.3 and slim optical disk drives, simplifying maintenance

•Fits 2x E3.S NVMe SSDs up to 7.5mm height
•Installs into standardized external 3.5” device bay (floppy bay)
•Uses a MCIO 8i connector, supporting PCIe 5.0 x4 with transfer speeds up to 128GB/s
•Supports hot-plug functionality for E3.S SSD (dependent on host environment)
•Comes equipped with a 25mm fan, which can be replaced without disassembling the entire unit
•Ruggedized full-metal enclosure and drive trays

•Supports 1 x 7.5mm height E3.S NVMe SSD
•Compatible with PCIe x4/ x8 /x16 Slot
•Supports PCIe Gen 5.0 x 4 speed up to 128Gbps
•Supports drive hot-plug without requiring the system to be powered down
•Active Power Technology (APT) – drive activity LED only powers up if there is a drive installed in the bay
•Optional 4-pin drive activity signal output - allows for easy transfer of the drive activity signal to the front of the computer case

•Fits into any 5.25" optical drive bay in computer cases or rackmount setups.
•Accommodates up to 8x 2.5" U.2/U.3 NVMe SSDs, supporting drives up to 7mm in height.
•Utilizes 4x MCIO 8i connectors, providing PCIe 5.0 x4 lanes with data transfer speeds up to 128GB/s.
•Removable drive caddy designed for tool-free, screw-less SSD installation and removal, allowing eight drives to be swapped simultaneously with ease.
•Dual 40x40x20mm fans for optimal airflow; fans are user-replaceable without disassembling the unit.
•Compatible with hot-swapping functionality for U.2/U.3 NVMe SSDs (host system must support hot-plug).
•Green LED indicators provide clear visual status for drive power and read/write activity.

•Designed for a 3.5" floppy bay in either a computer case or rackmount.
•Holds 2 x EDSFF E1.S NVMe SSDs (compatible with 9.5mm and 15mm heights).
•Uses a MCIO 8i connector, supporting PCIe 5.0 x4 with transfer speeds up to 128GB/s.
•Features a removable drive tray with tool-less SSD installation for user-friendly maintenance.
•Comes equipped with two 25mm fans, which can be replaced without disassembling the entire unit.
•Supports hot-swap functionality for EDSFF E1.S SSD (dependent on host environment).

•Fits into any 5.25" optical drive bay in computer cases or rackmount setups
•Accommodates up to 4x 2.5" U.2/U.3 NVMe SSDs, supporting drives up to 15mm in height
•Utilizes 2x MCIO 8i connectors, providing PCIe 5.0 x4 lanes with data transfer speeds up to 128GB/s
•Drive caddy designed for tool-free, screw-less SSD installation and removal, allowing four drives to be swapped simultaneously with ease
•Dual 40x40x20mm fans for optimal airflow; fans are user-replaceable without disassembling the unit
•Compatible with hot-swapping functionality for U.2/U.3 NVMe SSDs (host system must support hot-swap)
